Photogrammetry · Structured light · Laser
3D scanning and reality capture
We digitize everything from small objects to built spaces to produce point clouds and 3D meshes. We select the capture technology based on size, surface, required accuracy and how the data will be used downstream.
Sub-mm
Sub-millimeter accuracy on selected applications and equipment.
3 methods
Photogrammetry, structured light and laser for different scales and conditions.
3D-ready
Deliverables prepared for CAD, inspection, documentation or printing.
Service scope
Capabilities, applications and deliverables
We define the technical workflow based on the geometry, the functional requirements and the level of validation the project needs.
Capture
Technologies and scope
- Photogrammetry to reconstruct geometry from controlled photo sequences.
- Structured light to capture objects with high geometric data density.
- Laser to record surfaces, spaces and larger-scale assets.
- Capture plan adapted to hidden areas, reflective finishes and access constraints.
Deliverables
Processing and formats
- Aligned, cleaned point cloud for analysis or documentation.
- 3D mesh in STL or OBJ formats for visualization and manufacturing.
- Conversion to surfaces or a parametric solid through reverse engineering when required.
- Comparison against nominal CAD for dimensional inspection within a defined scope.
Applications
Where it adds value
The final setup is tailored to the industry, the part's use and the project's acceptance criteria.
Engineering
Parts without drawings
Capture existing geometry to rebuild, adapt or manufacture replacements.
Quality
Dimensional inspection
Compare actual surfaces against a CAD model and pinpoint deviations.
AECO
Space documentation
Record buildings, facilities and assets for BIM coordination and planning.
Process
A controlled workflow from start to finish
Each stage produces verifiable information to reduce rework and keep technical decisions traceable.
- 01
Define scope
We review size, surface, accuracy, accessibility and the required final format.
- 02
Capture
We carry out the scanning strategy with sufficient references and coverage.
- 03
Process
We align, clean and optimize the point cloud or mesh.
- 04
Deliver
We export the agreed formats and document relevant considerations.
Related services
Integrate the full workflow
Combine this service with other AxonID capabilities to move from capture or validation through to manufacturing and dimensional inspection.
Do you have files, drawings or a reference part?
Share the scope, quantity, material and expected timeline. We will review the information and propose the right technical workflow.
